Description
| Parameter | Value |
|---|---|
| MFR # | DWS780 |
| HORIZON # | HZ4191467SALES |
| UPC # | 885911231602 |
| Country of Origin | Taiwan, Province of China |
| Blade Dia. | 12 in |
| Arbor Size | 5/8 in, 1 in |
| Length | 23 1/2 in |
| Height | 19 3/4 in |
| Width | 30 1/2 in |
| Cord Length | 6 ft |
| Max. Cut Width @ 0 Deg. Miter | 13 3/4 in |
| Max. Cut Depth @ 0 Deg. Bevel | 6 3/4 in |
| Max. Cut Depth @ 45 Deg. Bevel | 4 1/2 in |
| Max. Cut Width @ 45 Deg. Miter | 9 1/2 in |
| Overall Length | 23 1/2 in |
| Overall Height | 19 3/4 in |
| Overall Width | 30 1/2 in |
| Cutting Width at 0 Degrees – Miter – Maximum | 13 3/4 in |
| Cutting Depth at 45 Degrees – Maximum | 4 1/2 in |
| Blade Diameter | 12 in |
| Cutting Depth at 0 Degrees – Maximum | 6 3/4 in |
| Cutting Width at 45 Degrees – Miter – Maximum | 9 1/2 in |
| Item | Miter Saw |
| Power Source | Corded |
| Max. Blade Speed | 3,800 RPM |
| Voltage | 120 V AC |
| Current | 15 A |
| Miter Angle Range | 60 Degrees Right to 50 Degrees Left |
| Bevel Angle Range | 49 Degrees Left to 49 Degrees Right |
| Sliding | Sliding |
| Features | XPS Cross Cut Positioning System |
| Bevel Capacity | 0 Degrees to 49 Degrees Left and Right |
| Corded/Cordless | Corded |
| Crosscut @ 90 Deg. H | 6-3/4″ |
| Crosscut @ 90 Deg. W | 13-3/4″ |
| Includes | Clamp, Dust Bag |
| No Load RPM | 3800 |
| Corded/Banded | Corded |
| Slide | Yes |
| Miter Capacity | 50 Degrees to 60 Degrees |
| Blade Type | 40T Carbide |
| Crosscut @ 45 Deg. H | 4-1/2″ |
| Bevel Stops | 9 Degrees |
| Crosscut @ 45 Deg. W | 9-1/2″ |
| Bevel | Yes |
| Amps | 15.0 |
| Item – Corded Miter Saws | Corded Miter Saw |
| Variable Speed | Yes |
| Arbor Shape | Round |
| Bevel Angle – Right | 49 Degrees |
| Blade Material | Carbide |
| Miter Angle – Left | 60 Degrees |
| Blade Speed – Maximum | 3,800 RPM |
| Plug Type | Two-Prong |
| Teeth per Inch | 40T |
| Bevel Angle – Left | 49 Degrees |
| Miter Angle – Right | 50 Degrees |
